Pallet changer PW 2000

Ideal for highly sensitive goods

The pallet changer PW 2000 encloses the goods very securely – two flexible side walls together with the rear wall secure the goods from three sides. Additional sliding plates ensure a particularly gentle exchange of pallets of highly sensitive goods. The pallet changer with its pushing method is particularly user friendly. The automatic operation with the integrated safety technology ensures an optimal exchange process.

  • pushing procedure for the exchange of pallets
  • Stand-Alone-unit
  • very user friendly
  • loading/unloading via pallet truck
  • sliding plates and flexible side walls
  • particularly suitable for highly sensitive goods

Data sheet

Layout

Make an inquiry

Specifications
  • performance: 10 – 30 changes/h
  • dimensions (L x W x H in mm): 3400 x 2300 x 2600
  • side walls: pneumatically adjustable
  • back wall: fixed
  • feeding & discharging: manual or electric pallet truck
  • control mode: automatic
  • power supply: 4 kVA – 16A 230/400 V R1/2“, 6 bar
  • machine weight: approx. 2500 kg
Pallet loading
  • total weight up to 1200 kg
  • standard pallet (W x L in mm): 800 – 1000 x 1200
  • max. height incl. pallet: 2000 mm
  • goods: e.g. cartons, drums, boxes, bags or bottles
  • overhang tolerance for each side: 50 mm
Options
  • sliding plate unit
  • stainless steel contact parts
  • goods height > 2000 mm
  • automatic/manual adjustment of pallet guides

Pallet exchange with the PW 2000

The pallet changer PW 2000 transfers goods safely and efficiently various kinds of loads from the source pallet to the target pallet. This applies even with sensitive goods which have gaps in the stacking. The two pneumatically flexible side walls embrace the goods gently. The back wall then closes in so that the goods are firmly secured from three sides and can be pushed to the target pallet. The frame, which is driven by an electric motor with frequency control, then pushes the goods gently across to the target pallet. Accordingly, the load configuration remains stable even in the case of small cardboard packaging and trays. The construction and configuration of the PW 2000 makes it particularly suitable for niche locations.

We recommend the PW 2000 pallet changer for 10 to 30 changes per hour.
